Techflex® ThermaShield® T6 Heat Reflective Wrap
Flexible Aluminized Fiberglass Thermal Wrap - Deflects Radiant Heat
0.0 / 5
Thermashield T6 Wrap Features
- Material: Aluminium Laminated Fiberglass
- Easy Wrap-Around Installation With High Temp Adhesive Closure Strip
- Will Not Burn or Support Combustion
- T6 is supplied in pre-cut 4' lengths
- Resists Common Chemicals & Solvents
- Extremely Abrasion and Cut Resistant
- Operating Temperature Range -76° to 392°F (-60° to 200°C.)
- Cuts Easily With Scissors
- Asbestos Free - RoHS Compliant
- 2,048°F / 1,120°C. Melt Temp
- Note: Measurements Are Listed as Inside Diameter.
One of the most popular items in the ThermaShield line of aluminized fiberglass products, Thermashield T6, is designed for ease of installation when component disassembly isn’t practical. Just wrap the pre-formed, split flexible tube around any component and seal the sides with the high-temperature adhesive strip to provide protection from hot pipes and engine components. The highly reflective aluminized exterior, combined with the insulating fiberglass interior, protects delicate wire bundles, cables, and lines from damage caused by nearby exhaust pipes, headers or other heat-generating components.
Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760
Product Sizes
| Size | Part Number | Width Max | Wall Thickness Max |
|---|---|---|---|
| 1/4" | T6F0.25SV | 1 13/16" | .042" |
| 3/8" | T6F0.38SV | 2 1/2" | .042" |
| 1/2" | T6F0.50SV | 3 3/8" | .042" |
| 5/8" | T6F0.63SV | 4 1/4" | .042" |
| 3/4" | T6F0.75SV | 5" | .042" |
| 1" | T6F1.00SV | 5 13/16" | .042" |
| 1 1/4" | T6F1.25SV | 6 11/16" | .042" |
| 1 1/2" | T6F1.50SV | 1 1/2" | .042" |
| 2" | T6F2.00SV | 7 3/8" | .042" |
Have a question that is not answered here? Please go to our Contact Us page and submit your question to us.
Looking for a quotation ? We would be happy to help by providing a quick response, inventory status, and Volume Level pricing, when available. Please fill out the form below and a representative will be in touch with you within hours to one business day to answer any questions and quote your request.
Product Details
One of the most popular items in the ThermaShield line of aluminized fiberglass products, Thermashield T6, is designed for ease of installation when component disassembly isn’t practical. Just wrap the pre-formed, split flexible tube around any component and seal the sides with the high-temperature adhesive strip to provide protection from hot pipes and engine components. The highly reflective aluminized exterior, combined with the insulating fiberglass interior, protects delicate wire bundles, cables, and lines from damage caused by nearby exhaust pipes, headers or other heat-generating components.
Product Specifications
Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760
Product Sizes
| Size | Part Number | Width Max | Wall Thickness Max |
|---|---|---|---|
| 1/4" | T6F0.25SV | 1 13/16" | .042" |
| 3/8" | T6F0.38SV | 2 1/2" | .042" |
| 1/2" | T6F0.50SV | 3 3/8" | .042" |
| 5/8" | T6F0.63SV | 4 1/4" | .042" |
| 3/4" | T6F0.75SV | 5" | .042" |
| 1" | T6F1.00SV | 5 13/16" | .042" |
| 1 1/4" | T6F1.25SV | 6 11/16" | .042" |
| 1 1/2" | T6F1.50SV | 1 1/2" | .042" |
| 2" | T6F2.00SV | 7 3/8" | .042" |
Product Manuals
Frequently Asked Questions
Have a question that is not answered here? Please go to our Contact Us page and submit your question to us.
