Techflex® Electrical Insulation Sleeving - Heavy Wall Silicone Coated
15,000 Volt, Rated to 392°F - UL Recognized
0.0 / 5
Heavy Wall Silicone Coated Flexglass Sleeving Features
- Length: 100 Ft
- Color: Red
- Rated to 392°F Class H (200°C)
- Cut & Abrasion Resistant
- Excellent Low Temperature Flexibility
- Up to 15,000 Volts; UL Recognized
- Resists Acids, Alkalis, and Alphatic Hydrocarbons
- Brittle Point Below -121°F (-85°C)
Inside Diameters Are Measured as Round Not Flat
Heavy Wall Flex Glass is engineered from a high-quality braided fiberglass sleeve surrounded by a heavy silicone rubber coating. Heavy Wall Flex Glass expands slightly for easy installation and is tough and flexible enough for use in tight radius applications. The silicone coating will expand and flex without cracks or fractures, and the treated fiberglass minimizes end fray and dusting during assembly and use. Heavy Wall Flex Glass resists dielectric breakdown caused by operational stresses. Heavy Wall Flex Glass is highly abrasion resistant and remains flexible in low temperature applications. It is also resistant to common chemicals, inorganic acids, alkalis and alphatic hydrocarbons. Rated to 392°F. (Class H), Heavy Wall Flex Glass is in extensive use in dry-type transformer applications and is ideal for terminal insulation and protection in a wide range of operating environments.
Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760
| Nominal Size | Diameter | Part# | Grade | Bulk Spool | Shop Spool | Available Colors |
|---|---|---|---|---|---|---|
| 3/8” | 0.375” | SGH0.38RD | 15000V | 100ft | N/A | Red (RD) |
| 1/2” | 0.500” | SGH0.50RD | 15000V | 100ft | N/A | Red (RD) |
| 3/4” | 0.750” | SGH0.75RD | 15000V | 100ft | N/A | Red (RD) |
Have a question that is not answered here? Please go to our Contact Us page and submit your question to us.
Looking for a quotation ? We would be happy to help by providing a quick response, inventory status, and Volume Level pricing, when available. Please fill out the form below and a representative will be in touch with you within hours to one business day to answer any questions and quote your request.
Product Details
Heavy Wall Flex Glass is engineered from a high-quality braided fiberglass sleeve surrounded by a heavy silicone rubber coating. Heavy Wall Flex Glass expands slightly for easy installation and is tough and flexible enough for use in tight radius applications. The silicone coating will expand and flex without cracks or fractures, and the treated fiberglass minimizes end fray and dusting during assembly and use. Heavy Wall Flex Glass resists dielectric breakdown caused by operational stresses. Heavy Wall Flex Glass is highly abrasion resistant and remains flexible in low temperature applications. It is also resistant to common chemicals, inorganic acids, alkalis and alphatic hydrocarbons. Rated to 392°F. (Class H), Heavy Wall Flex Glass is in extensive use in dry-type transformer applications and is ideal for terminal insulation and protection in a wide range of operating environments.
Product Specifications
Are we missing the specification you need? Please go to our Contact Us page and submit your question to us, or call 1-877-284-7760
| Nominal Size | Diameter | Part# | Grade | Bulk Spool | Shop Spool | Available Colors |
|---|---|---|---|---|---|---|
| 3/8” | 0.375” | SGH0.38RD | 15000V | 100ft | N/A | Red (RD) |
| 1/2” | 0.500” | SGH0.50RD | 15000V | 100ft | N/A | Red (RD) |
| 3/4” | 0.750” | SGH0.75RD | 15000V | 100ft | N/A | Red (RD) |
